Toyota RAV4 Wheel Hub 2015-2019
Toyota RAV4 Wheel Hub 2015-2019
Couldn't load pickup availability
Collapsible content
Description
Rear Wheel Bearing Fit 2015-2019 Lexus NX200T-NX300H, 2006-2018 Toyota RAV4 Wheel Hub 5 Lug- 512374
Fit
2015 2016 2017 Lexus NX200t
2015 2016 2017 Lexus NX200t F Sport
2018 2019 Lexus NX300 AWD
2018 2019 Lexus NX300 F Sport AWD
2015 2016 2017 2018 2019 Lexus NX300h
2006 07 08 09 10 11 12 13 14 15 16 17 18 Toyota RAV4 4WD
2006 07 08 09 10 11 12 13 14 15 16 17 18 Toyota RAV4 Adventure AWD
2006 07 08 09 10 11 12 13 14 15 16 17 18 Toyota RAV4 Hybrid Limited
2006 07 08 09 10 11 12 13 14 15 16 17 18 Toyota RAV4 Hybrid Limited AWD
2006 07 08 09 10 11 12 13 14 15 16 17 18 Toyota RAV4 Hybrid SE AWD
2006 07 08 09 10 11 12 13 14 15 16 17 18 Toyota RAV4 Hybrid XLE
2006 07 08 09 10 11 12 13 14 15 16 17 18 Toyota RAV4 Hybrid XLE AWD
2006 07 08 09 10 11 12 13 14 15 16 17 18 Toyota RAV4 LE 4WD, AWD
2006 07 08 09 10 11 12 13 14 15 16 17 18 Toyota RAV4 Limited 4WD, AWD
2006 07 08 09 10 11 12 13 14 15 16 17 18 Toyota RAV4 Platinum AWD
2006 07 08 09 10 11 12 13 14 15 16 17 18 Toyota RAV4 SE 4WD, AWD
2006 07 08 09 10 11 12 13 14 15 16 17 18 Toyota RAV4 Sport 4WD
2006 07 08 09 10 11 12 13 14 15 16 17 18 Toyota RAV4 XLE 4WD, AWD
Description:
Position:Driver (LH Left) or Passeger(RH Right) Side Rear
ABS Sensor Included: Yes
Wiring Harness Included: No
Number Of Mounting Bolts To Knuckle: 4
Number Of Lug Bolts Included: 5
Number Of Flange Bolts Included: 5
Driven Or Non-Driven: Driven
Number Of Splines: 26
ABS Ring Type: Encoder
Total Hub Diameter (in): 5.35 Inch
Hub Centerbore Diameter (in): 4.5 Inch
Total Hub Height (in): 6.457 Inch
Flange Diameter (in): 5.349 Inch
Flange Offset (in): 2.549 Inch
Hub Pilot Diameter (in): 2.99 Inch
Flange Shape: Square
Material: Steel
Bearing Type: Ball
