Toyota Highlander Wheel Hub 2010-2019

Toyota Highlander Wheel Hub 2010-2019

$49.95 USD
$59.99 USD $49.95 USD
Sale Sold out
Shipping calculated at checkout.
SKU: RB512365
View full details

Description

Rear Wheel Bearing Fit 2010-2019 Lexus RX350-RX450HL, Toyota Highlander Wheel Hub w/ABS, 5 Lugs AWD, 512365


Fit:

2010 11 12 13 14 15 16 17 18 19 Lexus RX350 AWD
2010 11 12 13 14 15 16 17 18 19 Lexus RX350 F Sport AWD
2018 2019 Lexus RX350L AWD
2010 11 12 13 14 15 16 17 18 19 Lexus RX450h AWD
2010 11 12 13 14 15 16 17 18 19 Lexus RX450h F Sport AWD
2018 2019 Lexus RX450hL AWD
2014 2015 2016 Toyota Highlander Hybrid Limited AWD
2014 2015 2016 Toyota Highlander LE AWD
2014 2015 2016 Toyota Highlander LE Plus AWD
2014 2015 2016 Toyota Highlander Limited AWD
2014 2015 2016 Toyota Highlander XLE AWD

Description:

Position:Driver (LH Left) or Passenger(RH Right) Rear
ABS Sensor Included: Yes
Wiring Harness Included: No
Number Of Mounting Bolts To Knuckle: 4
Number Of Lug Bolts Included: 5
Number Of Flange Bolts Included: 5
Driven Or Non-Driven: Driven
Number Of Splines: 26
ABS Ring Type: Encoder
Lug Bolt Thread Size: M12-1.50
Total Hub Diameter (in): 5.35 Inch
Total Hub Diameter (mm): 135.89mm
Hub Centerbore Diameter (in): 4.5 Inch
Hub Centerbore Diameter (mm): 114.3mm
Total Hub Height (in): 6.457 Inch
Total Hub Height (mm): 164mm
Flange Diameter (in): 5.349 Inch
Flange Diameter (mm): 135.89mm
Flange Offset (in): 2.549 Inch
Flange Offset (mm): 64.76mm
Flange Shape: Square
Material: Steel
Bearing Type: Ball
Hub Pilot Diameter (in): 3.42 Inch
Hub Pilot Diameter (mm): 86.9mm
